Touch Screen VFD Servo Inverter Control Box For Ball Mill 7.5KW-630KW

ACI DLT Series Ball Mill Servo Control Energy-Saving Cabinet

Ball mill servo control energy-saving cabinet is an advanced equipment that integrates servo control technology with energy-saving functions to optimize the operational efficiency of ball mills while reducing energy consumption.

I. Technical Features

1. Servo Control Technology
   • Precision Speed Regulation: Real-time adjustment of motor speed via a servo drive ensures the ball mill operates at optimal speeds during different grinding stages (e.g., coarse grinding, fine grinding), avoiding inefficiencies caused by constant-speed operation.
   • Dynamic Torque Compensation: Automatically adjusts motor output torque based on material characteristics and grinding load variations to ensure grinding effectiveness while reducing energy waste.
   • Multi-Speed Control: Supports multi-speed operation modes tailored to different process requirements, such as startup, acceleration, constant speed, and deceleration, enhancing equipment flexibility.
2. Energy-Saving Functions
   • Frequency Conversion Energy Saving: Utilizes frequency conversion technology to reduce motor power output during light load or no-load conditions, minimizing ineffective energy consumption.
   • Soft Start Function: Limits starting current (below rated current) to reduce impact on the power grid and extend equipment lifespan.
   • Power Factor Optimization: Improves power factor (up to 99%+) to reduce reactive power losses and enhance energy utilization efficiency.
3. Intelligent Control and Protection
   • Real-Time Monitoring and Feedback: Uses sensors to monitor motor current, voltage, temperature, and other parameters in real time, providing feedback to the control system for dynamic adjustments.
   • Fault Warning and Protection: Includes overload, overcurrent, short circuit, and grounding protection to ensure safe operation.
   • Remote Monitoring and Management: Supports remote monitoring and operation for centralized management and maintenance.

II. Application Advantages

1. Significant Energy-Saving Effects
   • Comprehensive energy-saving rates of 10%–35%, depending on process conditions and operating modes. For example, in the ceramic industry, energy-saving rates can reach 15%–25%.
   • Reduces operating costs, with payback periods typically within 5–12 months.
2. Enhanced Production Efficiency
   • Optimizes grinding effects through precise speed and torque control, improving product quality and production efficiency.
   • Reduces equipment wear, extending the lifespan of belts, gears, and other components.
3. Adaptability to Complex Conditions
   • Flexibly adjusts operating parameters based on different materials and process requirements, demonstrating strong adaptability.
   • Suitable for industries such as cement, ceramics, and mineral beneficiation, especially under high-load, long-duration operating conditions.
4. Environmental and Safety Benefits
   • Reduces energy consumption and carbon emissions, aligning with green production requirements.
   • Minimizes starting impact currents to avoid affecting the power grid and other equipment.

III. Key Functional Modules

1. Servo Drive
   • Responsible for precise motor control, supporting multiple operation modes and protection functions.
2. Frequency Converter
   • Enables smooth motor speed regulation to reduce energy consumption.
3. Human-Machine Interface (HMI)
   • Provides an intuitive operating interface for parameter setting, operation monitoring, and fault diagnosis.
4. Protection Module
   • Includes overload, overcurrent, short circuit, and grounding protection to ensure safe operation.
5. Communication Module
   • Supports communication with upper-level computers or remote monitoring systems for centralized management and data transmission.

IV. Application Scenarios

• Cement Industry: Used for grinding raw materials and cement to reduce energy consumption and improve production efficiency.
• Ceramic Industry: Optimizes ball mill grinding effects, reducing energy waste and equipment wear.
• Mineral Beneficiation Industry: Enhances ore grinding efficiency and lowers operating costs.
• Other Industries: Applicable in sectors such as chemicals and metallurgy where ball mills are in use.
